mesheryctl model init and build explained

If you are new to the Meshery ecosystem and want to create your own models, this post will show you how to do so using Meshery CLI (mesheryctl).

What is a Meshery Model?
Meshery models are reusable definitions of cloud-native infrastructure and workloads. They help you describe, package, and share your architecture.
Learn more about Meshery models.

Quick start a new model — a two‑step story

You have an idea and want to try it quickly with Meshery. In this short tutorial you will:

scaffold a new model with mesheryctl, then
build it into a runnable artifact.

Treat this as a skeleton: commands, expected behavior, and places to expand. Fill in examples, flags, and troubleshooting later.

Step 1 — scaffold: `mesheryctl model init`

Purpose: Generates a folder structure and guides the user on model creation.

Documentation: https://docs.meshery.io/reference/mesheryctl/model/init

In our example we will create a new model in a dedicated path in a specific format using the following values:

name: my-awesome-model
path: my-awesome-models
format: json

Create

Example:

In my destination path, nothing is present.

$ ~/my-awesome-models$ ls -l
total 0

Now you can create your scaffold by running the following command

$ mesheryctl model init my-awesome-model --path ./my-awesome-models --output-format json

Creating new Meshery model: my-awesome-model
Creating directory structure...
Generating model definition...
Adding sample components...
Creating sample relationships...
Adding sample connections...
Creating sample credentials...
Created my-awesome-model model at my-awesome-models/my-awesome-model

This command creates a new model named my-awesome-model in the my-awesome-models directory with the following structure:

$ my-awesome-models/
└── my-awesome-model
    └── v0.1.0
        ├── components
        │   └── component.json
        ├── connections
        ├── credentials
        ├── model.json
        └── relationships
            └── relationship.json

6 directories, 3 files

You can see that the required folders/files have been created.

Next steps:

cd /home/user/my-awesome-models/my-awesome-model
Edit model.json to customize your model configuration
Add your components in the components/ directory
Define relationships in the relationships/ directory
Add your connections in the connections/ directory
Define credentials in the credentials/ directory
Use mesheryctl model build to package your model

To import this model into Meshery:

$ mesheryctl model import /home/user/my-awesome-models/my-awesome-model

To export this model as OCI image:

mesheryctl model build my-awesome-model/v0.1.0 --path /home/user/my-awesome-models

Detailed guide: https://docs.meshery.io/guides/creating-new-model-with-mesheryctl

What this does (high level):

creates a directory with the model name and a subdirectory with the version of the model
generates the files needed for a valid model
Details each step
gives you the next actions to take

Let’s see what we have in the my-awesome-models folder

.
└── my-awesome-model
    └── v0.1.0
        ├── components
        │   └── component.json
        ├── connections
        ├── credentials
        ├── model.json
        └── relationships
            └── relationship.json

6 directories, 3 files

You can see that the required folders/files have been created.

Customize

Now customize the generated files to represent your model. If you need more than one component or relationship, copy the existing file(s) and adjust them accordingly.

Below are the contents of the generated files; they are provided only to show what is required.

model.json


{
  "id": "00000000-0000-0000-0000-000000000000",
  "schemaVersion": "models.meshery.io/v1beta1",
  "version": "v0.0.1",
  "name": "untitled-model",
  "displayName": "Untitled Model",
  "description": "A new Meshery model.",
  "status": "enabled",
  "registrant": {
    "id": "00000000-0000-0000-0000-000000000000",
    "name": "",
    "credential_id": "00000000-0000-0000-0000-000000000000",
    "type": "",
    "sub_type": "",
    "kind": "artifacthub",
    "status": "",
    "user_id": "00000000-0000-0000-0000-000000000000",
    "created_at": "0001-01-01T00:00:00Z",
    "updated_at": "0001-01-01T00:00:00Z",
    "deleted_at": null,
    "schemaVersion": "connections.meshery.io/v1beta1",
    "environments": [
      {
        "id": "00000000-0000-0000-0000-000000000000",
        "name": "",
        "description": "",
        "organization_id": "00000000-0000-0000-0000-000000000000",
        "owner": "00000000-0000-0000-0000-000000000000",
        "created_at": "0001-01-01T00:00:00Z",
        "updated_at": "0001-01-01T00:00:00Z",
        "deleted_at": null,
        "schemaVersion": "environments.meshery.io/v1beta1"
      }
    ]
  },
  "metadata": {
    "capabilities": [],
    "primaryColor": "#00b39f",
    "secondaryColor": "#00D3A9",
    "svgWhite": "<svg width=\"32\" height=\"32\" viewBox=\"0 0 32 32\" fill=\"none\" xmlns=\"<http://www.w3.org/2000/svg\">><path d=\"M16.405 8.732v6.57l5.694-3.297-5.694-3.273Zm0 7.942v6.602l5.747-3.285-5.747-3.317Z\" fill=\"#fff\"/><path d=\"M15.586 15.256v-6.47l-5.622 3.225 5.622 3.245ZM4.307 23.252a13.809 13.809 0 0 0 4.362 4.39v-6.914l-4.362 2.524Zm11.279-.008v-6.52L9.95 19.985l5.636 3.258Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"m9.49 27.23 5.707-3.263-5.707-3.3v6.563Z\" fill=\"#fff\"/><path d=\"M22.54 27.265v-6.553l-5.699 3.259 5.7 3.294Zm5.58-4.773a13.697 13.697 0 0 0 1.612-5.895l-5.934 3.397 4.323 2.498Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"m23.362 19.298 5.728-3.276-5.728-3.291v6.567Z\" fill=\"#fff\"/><path d=\"M22.541 11.315V4.8l-5.673 3.253 5.673 3.262Zm0 7.955v-6.574l-5.685 3.292 5.685 3.281Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M9.49 12.684v6.622l5.728-3.316-5.728-3.306Z\" fill=\"#fff\"/><path d=\"M15.586 2.25a13.69 13.69 0 0 0-6.037 1.595l6.037 3.463V2.25Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M9.49 4.756v6.583l5.732-3.288L9.49 4.756Z\" fill=\"#fff\"/><path d=\"M8.669 4.356a13.83 13.83 0 0 0-4.362 4.39l4.362 2.518V4.356Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M22.504 3.88a13.695 13.695 0 0 0-6.099-1.63v5.123l6.1-3.493ZM2.25 16.483c.071 2.12.634 4.196 1.644 6.062l4.418-2.559-6.062-3.503Zm1.644-7.028a13.68 13.68 0 0 0-1.644 6.036l6.068-3.482-4.424-2.554Z\" fill=\"#fff\"/><path d=\"M9.539 28.147a13.673 13.673 0 0 0 6.047 1.603v-5.062L9.54 28.147Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M27.697 8.768a13.83 13.83 0 0 0-4.335-4.383v6.889l4.335-2.506ZM23.362 27.62a13.851 13.851 0 0 0 4.351-4.417l-4.351-2.514v6.93Z\" fill=\"#fff\"/><path d=\"M29.75 15.452a13.659 13.659 0 0 0-1.63-5.979l-4.381 2.53 6.011 3.45Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M16.405 29.75a13.673 13.673 0 0 0 6.036-1.595l-6.036-3.498v5.093Z\" fill=\"#fff\"/><path d=\"M8.669 19.247v-6.494L3.03 15.986l5.639 3.261Z\" fill=\"#fff\" fill-opacity=\".8\"/></svg>",
    "svgColor": "<svg xmlns=\"<http://www.w3.org/2000/svg\>" id=\"Layer_1\" data-name=\"Layer 1\" viewBox=\"0 0 134.95 135.02\">meshery-logo-light<polygon points=\"69.49 31.82 69.49 64.07 97.44 47.89 69.49 31.82\" class=\"cls-1\"/><polygon points=\"69.49 70.81 69.49 103.22 97.7 87.09 69.49 70.81\" class=\"cls-1\"/><polygon points=\"65.47 63.85 65.47 32.09 37.87 47.92 65.47 63.85\" class=\"cls-2\"/><path d=\"M10.1,103.1a67.79,67.79,0,0,0,21.41,21.55V90.71Z\" class=\"cls-2\"/><polygon points=\"65.47 103.06 65.47 71.05 37.8 87.07 65.47 103.06\" class=\"cls-2\"/><polygon points=\"35.54 122.63 63.56 106.61 35.54 90.41 35.54 122.63\" class=\"cls-1\"/><polygon points=\"99.61 122.8 99.61 90.63 71.63 106.63 99.61 122.8\" class=\"cls-2\"/><path d=\"M127,99.37a67.22,67.22,0,0,0,7.91-28.94L105.78,87.11Z\" class=\"cls-2\"/><polygon points=\"103.64 83.69 131.76 67.61 103.64 51.45 103.64 83.69\" class=\"cls-1\"/><polygon points=\"99.61 44.5 99.61 12.52 71.76 28.49 99.61 44.5\" class=\"cls-2\"/><polygon points=\"99.61 83.55 99.61 51.28 71.7 67.44 99.61 83.55\" class=\"cls-2\"/><polygon points=\"67.48 135.02 67.49 135.02 67.48 135.02 67.48 135.02\" class=\"cls-2\"/><polygon points=\"35.54 51.22 35.54 83.73 63.66 67.45 35.54 51.22\" class=\"cls-1\"/><path d=\"M65.47,0A67.2,67.2,0,0,0,35.83,7.83l29.64,17Z\" class=\"cls-2\"/><polygon points=\"35.54 12.3 35.54 44.62 63.68 28.48 35.54 12.3\" class=\"cls-1\"/><path d=\"M31.51,10.34A67.89,67.89,0,0,0,10.1,31.89L31.51,44.25Z\" class=\"cls-2\"/><path d=\"M99.43,8A67.23,67.23,0,0,0,69.49,0V25.15Z\" class=\"cls-1\"/><path d=\"M0,69.87A67.27,67.27,0,0,0,8.07,99.63L29.76,87.07Z\" class=\"cls-1\"/><path d=\"M8.07,35.37A67.16,67.16,0,0,0,0,65L29.79,47.91Z\" class=\"cls-1\"/><path d=\"M35.78,127.13A67.13,67.13,0,0,0,65.47,135V110.15Z\" class=\"cls-2\"/><path d=\"M124.92,32a67.9,67.9,0,0,0-21.28-21.52V44.3Z\" class=\"cls-1\"/><path d=\"M103.64,124.54A68,68,0,0,0,125,102.86L103.64,90.52Z\" class=\"cls-1\"/><path d=\"M135,64.81a67.06,67.06,0,0,0-8-29.35L105.49,47.88Z\" class=\"cls-2\"/><path d=\"M69.49,135a67.12,67.12,0,0,0,29.63-7.83L69.49,110Z\" class=\"cls-1\"/><polygon points=\"31.51 83.44 31.51 51.56 3.83 67.43 31.51 83.44\" class=\"cls-2\"/></svg>",
    "svgComplete": "",
    "shape": "circle",
    "isAnnotation": false
  },
  "registrantId": "00000000-0000-0000-0000-000000000000",
  "categoryId": "00000000-0000-0000-0000-000000000000",
  "category": {
    "id": "00000000-0000-0000-0000-000000000000",
    "name": "Uncategorized"
  },
  "subCategory": "Uncategorized",
  "model": {
    "version": "v0.0.1"
  },
  "componentsCount": 0,
  "relationshipsCount": 0
}

component.json


  {
    "id": "00000000-0000-0000-0000-000000000000",
    "schemaVersion": "components.meshery.io/v1beta1",
    "version": "v0.0.1",
    "displayName": "Untitled Component",
    "description": "A new Meshery Component.",
    "format": "JSON",
    "model": {
      "id": "00000000-0000-0000-0000-000000000000",
      "schemaVersion": "models.meshery.io/v1beta1",
      "version": "v0.0.1",
      "name": "untitled-model",
      "displayName": "Untitled Model",
      "description": "A new Meshery model.",
      "status": "enabled",
      ...
    },
    ...
  }
{
  "id": "00000000-0000-0000-0000-000000000000",
  "schemaVersion": "components.meshery.io/v1beta1",
  "version": "v0.0.1",
  "displayName": "Untitled Component",
  "description": "A new Meshery Component.",
  "format": "JSON",
  "model": {
    "id": "00000000-0000-0000-0000-000000000000",
    "schemaVersion": "models.meshery.io/v1beta1",
    "version": "v0.0.1",
    "name": "untitled-model",
    "displayName": "Untitled Model",
    "description": "A new Meshery model.",
    "status": "enabled",
    "registrant": {
      "id": "00000000-0000-0000-0000-000000000000",
      "name": "",
      "credential_id": "00000000-0000-0000-0000-000000000000",
      "type": "",
      "sub_type": "",
      "kind": "artifacthub",
      "status": "",
      "user_id": "00000000-0000-0000-0000-000000000000",
      "created_at": "0001-01-01T00:00:00Z",
      "updated_at": "0001-01-01T00:00:00Z",
      "deleted_at": null,
      "schemaVersion": "connections.meshery.io/v1beta1",
      "environments": [
        {
          "id": "00000000-0000-0000-0000-000000000000",
          "name": "",
          "description": "",
          "organization_id": "00000000-0000-0000-0000-000000000000",
          "owner": "00000000-0000-0000-0000-000000000000",
          "created_at": "0001-01-01T00:00:00Z",
          "updated_at": "0001-01-01T00:00:00Z",
          "deleted_at": null,
          "schemaVersion": "environments.meshery.io/v1beta1"
        }
      ]
    },
    "metadata": {
      "capabilities": [],
      "primaryColor": "#00b39f",
      "secondaryColor": "#00D3A9",
      "svgWhite": "<svg width=\"32\" height=\"32\" viewBox=\"0 0 32 32\" fill=\"none\" xmlns=\"<http://www.w3.org/2000/svg\">><path d=\"M16.405 8.732v6.57l5.694-3.297-5.694-3.273Zm0 7.942v6.602l5.747-3.285-5.747-3.317Z\" fill=\"#fff\"/><path d=\"M15.586 15.256v-6.47l-5.622 3.225 5.622 3.245ZM4.307 23.252a13.809 13.809 0 0 0 4.362 4.39v-6.914l-4.362 2.524Zm11.279-.008v-6.52L9.95 19.985l5.636 3.258Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"m9.49 27.23 5.707-3.263-5.707-3.3v6.563Z\" fill=\"#fff\"/><path d=\"M22.54 27.265v-6.553l-5.699 3.259 5.7 3.294Zm5.58-4.773a13.697 13.697 0 0 0 1.612-5.895l-5.934 3.397 4.323 2.498Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"m23.362 19.298 5.728-3.276-5.728-3.291v6.567Z\" fill=\"#fff\"/><path d=\"M22.541 11.315V4.8l-5.673 3.253 5.673 3.262Zm0 7.955v-6.574l-5.685 3.292 5.685 3.281Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M9.49 12.684v6.622l5.728-3.316-5.728-3.306Z\" fill=\"#fff\"/><path d=\"M15.586 2.25a13.69 13.69 0 0 0-6.037 1.595l6.037 3.463V2.25Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M9.49 4.756v6.583l5.732-3.288L9.49 4.756Z\" fill=\"#fff\"/><path d=\"M8.669 4.356a13.83 13.83 0 0 0-4.362 4.39l4.362 2.518V4.356Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M22.504 3.88a13.695 13.695 0 0 0-6.099-1.63v5.123l6.1-3.493ZM2.25 16.483c.071 2.12.634 4.196 1.644 6.062l4.418-2.559-6.062-3.503Zm1.644-7.028a13.68 13.68 0 0 0-1.644 6.036l6.068-3.482-4.424-2.554Z\" fill=\"#fff\"/><path d=\"M9.539 28.147a13.673 13.673 0 0 0 6.047 1.603v-5.062L9.54 28.147Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M27.697 8.768a13.83 13.83 0 0 0-4.335-4.383v6.889l4.335-2.506ZM23.362 27.62a13.851 13.851 0 0 0 4.351-4.417l-4.351-2.514v6.93Z\" fill=\"#fff\"/><path d=\"M29.75 15.452a13.659 13.659 0 0 0-1.63-5.979l-4.381 2.53 6.011 3.45Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M16.405 29.75a13.673 13.673 0 0 0 6.036-1.595l-6.036-3.498v5.093Z\" fill=\"#fff\"/><path d=\"M8.669 19.247v-6.494L3.03 15.986l5.639 3.261Z\" fill=\"#fff\" fill-opacity=\".8\"/></svg>",
      "svgColor": "<svg xmlns=\"<http://www.w3.org/2000/svg\>" id=\"Layer_1\" data-name=\"Layer 1\" viewBox=\"0 0 134.95 135.02\">meshery-logo-light<polygon points=\"69.49 31.82 69.49 64.07 97.44 47.89 69.49 31.82\" class=\"cls-1\"/><polygon points=\"69.49 70.81 69.49 103.22 97.7 87.09 69.49 70.81\" class=\"cls-1\"/><polygon points=\"65.47 63.85 65.47 32.09 37.87 47.92 65.47 63.85\" class=\"cls-2\"/><path d=\"M10.1,103.1a67.79,67.79,0,0,0,21.41,21.55V90.71Z\" class=\"cls-2\"/><polygon points=\"65.47 103.06 65.47 71.05 37.8 87.07 65.47 103.06\" class=\"cls-2\"/><polygon points=\"35.54 122.63 63.56 106.61 35.54 90.41 35.54 122.63\" class=\"cls-1\"/><polygon points=\"99.61 122.8 99.61 90.63 71.63 106.63 99.61 122.8\" class=\"cls-2\"/><path d=\"M127,99.37a67.22,67.22,0,0,0,7.91-28.94L105.78,87.11Z\" class=\"cls-2\"/><polygon points=\"103.64 83.69 131.76 67.61 103.64 51.45 103.64 83.69\" class=\"cls-1\"/><polygon points=\"99.61 44.5 99.61 12.52 71.76 28.49 99.61 44.5\" class=\"cls-2\"/><polygon points=\"99.61 83.55 99.61 51.28 71.7 67.44 99.61 83.55\" class=\"cls-2\"/><polygon points=\"67.48 135.02 67.49 135.02 67.48 135.02 67.48 135.02\" class=\"cls-2\"/><polygon points=\"35.54 51.22 35.54 83.73 63.66 67.45 35.54 51.22\" class=\"cls-1\"/><path d=\"M65.47,0A67.2,67.2,0,0,0,35.83,7.83l29.64,17Z\" class=\"cls-2\"/><polygon points=\"35.54 12.3 35.54 44.62 63.68 28.48 35.54 12.3\" class=\"cls-1\"/><path d=\"M31.51,10.34A67.89,67.89,0,0,0,10.1,31.89L31.51,44.25Z\" class=\"cls-2\"/><path d=\"M99.43,8A67.23,67.23,0,0,0,69.49,0V25.15Z\" class=\"cls-1\"/><path d=\"M0,69.87A67.27,67.27,0,0,0,8.07,99.63L29.76,87.07Z\" class=\"cls-1\"/><path d=\"M8.07,35.37A67.16,67.16,0,0,0,0,65L29.79,47.91Z\" class=\"cls-1\"/><path d=\"M35.78,127.13A67.13,67.13,0,0,0,65.47,135V110.15Z\" class=\"cls-2\"/><path d=\"M124.92,32a67.9,67.9,0,0,0-21.28-21.52V44.3Z\" class=\"cls-1\"/><path d=\"M103.64,124.54A68,68,0,0,0,125,102.86L103.64,90.52Z\" class=\"cls-1\"/><path d=\"M135,64.81a67.06,67.06,0,0,0-8-29.35L105.49,47.88Z\" class=\"cls-2\"/><path d=\"M69.49,135a67.12,67.12,0,0,0,29.63-7.83L69.49,110Z\" class=\"cls-1\"/><polygon points=\"31.51 83.44 31.51 51.56 3.83 67.43 31.51 83.44\" class=\"cls-2\"/></svg>",
      "svgComplete": "",
      "shape": "circle",
      "isAnnotation": false
    },
    "registrantId": "00000000-0000-0000-0000-000000000000",
    "categoryId": "00000000-0000-0000-0000-000000000000",
    "category": {
      "id": "00000000-0000-0000-0000-000000000000",
      "name": "Uncategorized"
    },
    "subCategory": "Uncategorized",
    "model": {
      "version": "v0.0.1"
    },
    "componentsCount": 0,
    "relationshipsCount": 0
  },
  "registrant": {},
  "metadata": {
    "genealogy": "",
    "configurationUISchema": "",
    "isAnnotation": false
  },
  "category": {},
  "modelId": "00000000-0000-0000-0000-000000000000",
  "styles": {
    "primaryColor": "",
    "secondaryColor": "",
    "svgWhite": "",
    "svgColor": "",
    "svgComplete": "",
    "color": "",
    "font-family": "",
    "font-size": "",
    "font-style": "",
    "font-weight": "",
    "text-transform": "",
    "label": "",
    "shape": "",
    "position": {},
    "body-text": "",
    "body-text-wrap": "",
    "body-text-max-width": "",
    "body-text-background-color": "",
    "body-text-color": "",
    "body-text-font-weight": "",
    "body-text-horizontal-align": "",
    "body-text-decoration": "",
    "body-text-vertical-align": "",
    "background-image": "",
    "background-color": "",
    "background-position-x": "",
    "background-position-y": "",
    "background-offset-x": "",
    "background-offset-y": "",
    "background-fit": "",
    "background-clip": "",
    "background-width-relative-to": "",
    "background-height-relative-to": "",
    "border-style": "",
    "border-color": "",
    "text-halign": "",
    "text-valign": "",
    "ghost": "no",
    "active-bg-color": "",
    "active-bg-opacity": "",
    "active-bg-size": "",
    "selection-box-color": "",
    "outside-texture-bg-color": "",
    "shape-polygon-points": "",
    "menu-background-color": "",
    "menu-forground-color": ""
  },
  "animation": {},
  "position": {},
  "capabilities": [
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Performance Test",
      "description": "Initiate a performance test. Meshery will execute the load generation, collect metrics, and present the results.",
      "kind": "action",
      "type": "operator",
      "subType": "perf-test",
      "key": "",
      "entityState": [
        "instance"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Workload Configuration",
      "description": "Configure the workload specific setting of a component",
      "kind": "mutate",
      "type": "configuration",
      "subType": "config",
      "key": "",
      "entityState": [
        "declaration"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Labels and Annotations Configuration",
      "description": "Configure Labels And Annotations for  the component ",
      "kind": "mutate",
      "type": "configuration",
      "subType": "labels-and-annotations",
      "key": "",
      "entityState": [
        "declaration"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Relationships",
      "description": "View relationships for the component",
      "kind": "view",
      "type": "configuration",
      "subType": "relationship",
      "key": "",
      "entityState": [
        "declaration",
        "instance"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Json Schema",
      "description": "View Component Definition ",
      "kind": "view",
      "type": "configuration",
      "subType": "definition",
      "key": "",
      "entityState": [
        "declaration",
        "instance"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Styling",
      "description": "Configure the visual styles for the component",
      "kind": "mutate",
      "type": "style",
      "subType": "",
      "key": "",
      "entityState": [
        "declaration"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Change Shape",
      "description": "Change the shape of the component",
      "kind": "mutate",
      "type": "style",
      "subType": "shape",
      "key": "",
      "entityState": [
        "declaration"
      ],
      "status": "enabled",
      "metadata": null
    },
    {
      "schemaVersion": "capability.meshery.io/v1alpha1",
      "version": "0.7.0",
      "displayName": "Compound Drag And Drop",
      "description": "Drag and Drop a component into a parent component in graph view",
      "kind": "interaction",
      "type": "graph",
      "subType": "compoundDnd",
      "key": "",
      "entityState": [
        "declaration"
      ],
      "status": "enabled",
      "metadata": null
    }
  ],
  "status": "enabled",
  "instanceDetails": {},
  "configuration": {},
  "component": {
    "version": "",
    "kind": "",
    "schema": ""
  }
}

relationship.json



{
  "id": "00000000-0000-0000-0000-000000000000",
  "schemaVersion": "relationships.meshery.io/v1alpha3",
  "version": "v0.0.1",
  "model": {
    "id": "00000000-0000-0000-0000-000000000000",
    "schemaVersion": "models.meshery.io/v1beta1",
    "version": "v0.0.1",
    "name": "untitled-model",
    "displayName": "Untitled Model",
    "description": "A new Meshery model.",
    "status": "enabled",
    "registrant": {
      "id": "00000000-0000-0000-0000-000000000000",
      "name": "",
      "credential_id": "00000000-0000-0000-0000-000000000000",
      "type": "",
      "sub_type": "",
      "kind": "artifacthub",
      "status": "",
      "user_id": "00000000-0000-0000-0000-000000000000",
      "created_at": "0001-01-01T00:00:00Z",
      "updated_at": "0001-01-01T00:00:00Z",
      "deleted_at": null,
      "schemaVersion": "connections.meshery.io/v1beta1",
      "environments": [
        {
          "id": "00000000-0000-0000-0000-000000000000",
          "name": "",
          "description": "",
          "organization_id": "00000000-0000-0000-0000-000000000000",
          "owner": "00000000-0000-0000-0000-000000000000",
          "created_at": "0001-01-01T00:00:00Z",
          "updated_at": "0001-01-01T00:00:00Z",
          "deleted_at": null,
          "schemaVersion": "environments.meshery.io/v1beta1"
        }
      ]
    },
    "metadata": {
      "capabilities": [],
      "primaryColor": "#00b39f",
      "secondaryColor": "#00D3A9",
      "svgWhite": "<svg width=\"32\" height=\"32\" viewBox=\"0 0 32 32\" fill=\"none\" xmlns=\"<http://www.w3.org/2000/svg\">><path d=\"M16.405 8.732v6.57l5.694-3.297-5.694-3.273Zm0 7.942v6.602l5.747-3.285-5.747-3.317Z\" fill=\"#fff\"/><path d=\"M15.586 15.256v-6.47l-5.622 3.225 5.622 3.245ZM4.307 23.252a13.809 13.809 0 0 0 4.362 4.39v-6.914l-4.362 2.524Zm11.279-.008v-6.52L9.95 19.985l5.636 3.258Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"m9.49 27.23 5.707-3.263-5.707-3.3v6.563Z\" fill=\"#fff\"/><path d=\"M22.54 27.265v-6.553l-5.699 3.259 5.7 3.294Zm5.58-4.773a13.697 13.697 0 0 0 1.612-5.895l-5.934 3.397 4.323 2.498Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"m23.362 19.298 5.728-3.276-5.728-3.291v6.567Z\" fill=\"#fff\"/><path d=\"M22.541 11.315V4.8l-5.673 3.253 5.673 3.262Zm0 7.955v-6.574l-5.685 3.292 5.685 3.281Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M9.49 12.684v6.622l5.728-3.316-5.728-3.306Z\" fill=\"#fff\"/><path d=\"M15.586 2.25a13.69 13.69 0 0 0-6.037 1.595l6.037 3.463V2.25Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M9.49 4.756v6.583l5.732-3.288L9.49 4.756Z\" fill=\"#fff\"/><path d=\"M8.669 4.356a13.83 13.83 0 0 0-4.362 4.39l4.362 2.518V4.356Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M22.504 3.88a13.695 13.695 0 0 0-6.099-1.63v5.123l6.1-3.493ZM2.25 16.483c.071 2.12.634 4.196 1.644 6.062l4.418-2.559-6.062-3.503Zm1.644-7.028a13.68 13.68 0 0 0-1.644 6.036l6.068-3.482-4.424-2.554Z\" fill=\"#fff\"/><path d=\"M9.539 28.147a13.673 13.673 0 0 0 6.047 1.603v-5.062L9.54 28.147Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M27.697 8.768a13.83 13.83 0 0 0-4.335-4.383v6.889l4.335-2.506ZM23.362 27.62a13.851 13.851 0 0 0 4.351-4.417l-4.351-2.514v6.93Z\" fill=\"#fff\"/><path d=\"M29.75 15.452a13.659 13.659 0 0 0-1.63-5.979l-4.381 2.53 6.011 3.45Z\" fill=\"#fff\" fill-opacity=\".8\"/><path d=\"M16.405 29.75a13.673 13.673 0 0 0 6.036-1.595l-6.036-3.498v5.093Z\" fill=\"#fff\"/><path d=\"M8.669 19.247v-6.494L3.03 15.986l5.639 3.261Z\" fill=\"#fff\" fill-opacity=\".8\"/></svg>",
      "svgColor": "<svg xmlns=\"<http://www.w3.org/2000/svg\>" id=\"Layer_1\" data-name=\"Layer 1\" viewBox=\"0 0 134.95 135.02\">meshery-logo-light<polygon points=\"69.49 31.82 69.49 64.07 97.44 47.89 69.49 31.82\" class=\"cls-1\"/><polygon points=\"69.49 70.81 69.49 103.22 97.7 87.09 69.49 70.81\" class=\"cls-1\"/><polygon points=\"65.47 63.85 65.47 32.09 37.87 47.92 65.47 63.85\" class=\"cls-2\"/><path d=\"M10.1,103.1a67.79,67.79,0,0,0,21.41,21.55V90.71Z\" class=\"cls-2\"/><polygon points=\"65.47 103.06 65.47 71.05 37.8 87.07 65.47 103.06\" class=\"cls-2\"/><polygon points=\"35.54 122.63 63.56 106.61 35.54 90.41 35.54 122.63\" class=\"cls-1\"/><polygon points=\"99.61 122.8 99.61 90.63 71.63 106.63 99.61 122.8\" class=\"cls-2\"/><path d=\"M127,99.37a67.22,67.22,0,0,0,7.91-28.94L105.78,87.11Z\" class=\"cls-2\"/><polygon points=\"103.64 83.69 131.76 67.61 103.64 51.45 103.64 83.69\" class=\"cls-1\"/><polygon points=\"99.61 44.5 99.61 12.52 71.76 28.49 99.61 44.5\" class=\"cls-2\"/><polygon points=\"99.61 83.55 99.61 51.28 71.7 67.44 99.61 83.55\" class=\"cls-2\"/><polygon points=\"67.48 135.02 67.49 135.02 67.48 135.02 67.48 135.02\" class=\"cls-2\"/><polygon points=\"35.54 51.22 35.54 83.73 63.66 67.45 35.54 51.22\" class=\"cls-1\"/><path d=\"M65.47,0A67.2,67.2,0,0,0,35.83,7.83l29.64,17Z\" class=\"cls-2\"/><polygon points=\"35.54 12.3 35.54 44.62 63.68 28.48 35.54 12.3\" class=\"cls-1\"/><path d=\"M31.51,10.34A67.89,67.89,0,0,0,10.1,31.89L31.51,44.25Z\" class=\"cls-2\"/><path d=\"M99.43,8A67.23,67.23,0,0,0,69.49,0V25.15Z\" class=\"cls-1\"/><path d=\"M0,69.87A67.27,67.27,0,0,0,8.07,99.63L29.76,87.07Z\" class=\"cls-1\"/><path d=\"M8.07,35.37A67.16,67.16,0,0,0,0,65L29.79,47.91Z\" class=\"cls-1\"/><path d=\"M35.78,127.13A67.13,67.13,0,0,0,65.47,135V110.15Z\" class=\"cls-2\"/><path d=\"M124.92,32a67.9,67.9,0,0,0-21.28-21.52V44.3Z\" class=\"cls-1\"/><path d=\"M103.64,124.54A68,68,0,0,0,125,102.86L103.64,90.52Z\" class=\"cls-1\"/><path d=\"M135,64.81a67.06,67.06,0,0,0-8-29.35L105.49,47.88Z\" class=\"cls-2\"/><path d=\"M69.49,135a67.12,67.12,0,0,0,29.63-7.83L69.49,110Z\" class=\"cls-1\"/><polygon points=\"31.51 83.44 31.51 51.56 3.83 67.43 31.51 83.44\" class=\"cls-2\"/></svg>",
      "svgComplete": "",
      "shape": "circle",
      "isAnnotation": false
    },
    "registrantId": "00000000-0000-0000-0000-000000000000",
    "categoryId": "00000000-0000-0000-0000-000000000000",
    "category": {
      "id": "00000000-0000-0000-0000-000000000000",
      "name": "Uncategorized"
    },
    "subCategory": "Uncategorized",
    "model": {
      "version": "v0.0.1"
    },
    "componentsCount": 0,
    "relationshipsCount": 0
  },
  "metadata": {},
  "kind": "hierarchical",
  "subType": "inventory",
  "type": "parent",
  "status": "enabled",
  "evaluationQuery": "",
  "capabilities": [],
  "selectors": []
}

Step 2 — build: `mesheryctl model build`

Purpose: Create an OCI-compliant package from the model files.

Documentation: https://docs.meshery.io/reference/mesheryctl/model/build

Example:

Now you have already customized your model and want to create an artifact.

name: my-awesome-model
path: my-awesome-models
version: v0.1.0

Be sure to move into the folder where the model was created (here: my-awesome-models)

# move in the root folder where you store your models

~/$ cd ~/my-awesome-models

~/my-awesome-models$ mesheryctl model build my-awesome-model/v0.1.0
Building meshery model from path my-awesome-model/v0.1.0
Saving OCI artifact as my-awesome-model-v0-1-0.tar

What this does (high level):

build the model from the path provided
save it as an OCI artifact

Let’s see what we have in my-awesome-models folder

.
├── my-awesome-model
│   └── v0.1.0
│       ├── components
│       │   └── component.json
│       ├── connections
│       ├── credentials
│       ├── model.json
│       └── relationships
│           └── relationship.json
└── my-awesome-model-v0-1-0.tar

6 directories, 4 files

You can see that an artifact has been generated properly

What to expect next

If you would like to use that model, we will have another dedicated tutorial post to achieve this.

I hope this quick introduction gives you a starting point to create your own model and enjoy the tools provided in the Meshery ecosystem.

How to start a new model from scratch using mesheryctl
